spare wheel carrier mod for 33" wheels

Post by mudmagnet » Sat Oct 10, 2015 12:47 pm

after buying a 265/75/16 spare tyre it wouldn't fit on the spare wheel carrier as it was too big
so a quick look online and found that if you flip the carrier upside down and drilled some new holes with a bit of modding all will be good


so off came the carrier and spacers and if you leave the spacers the right way up then turn the carrier 180 you can get to see where to drill the holes




Holes drilled




then i marked out where to cut a hole to miss the rear wiper arm as now it is flipped upside down the wiper arm hits the top of the carrier




Hole cut and carrier cleaned up and painted,
i don't like fitting rusty things back on :D




and finally with the new wheel on and there is about 10mm gap between bumper and tyre
my 265/75/16 measure about 32" so you should just about get a 33" tyre on the carrier with this mod and the best part is it does'nt cost a penny unless you paint it like I did


i'm so skint i cant even pay attention

User avatar
Alterastro
Moderator
Posts: 5496
Joined: Sun Mar 30, 2008 8:42 pm
Vehicle: Nissan Patrol LWB Aussie import - 4.8litre petrol but with LPG!!
Real Name: Nick
Location: Slurrey
Contact:

Re: spare wheel carrier mod for 33" wheels

Post by Alterastro » Sat Oct 10, 2015 1:20 pm

Nice one Gav :gr8:

User avatar
mudmagnet
Laning Co-ordinator
Posts: 3169
Joined: Sun Jun 29, 2008 4:51 pm
Vehicle: td5 disco
Real Name: gavin
Location: Farnborough Hampshire

Re: spare wheel carrier mod for 33" wheels

Post by mudmagnet » Sat Oct 10, 2015 1:33 pm

Thanks nick
i'm so skint i cant even pay attention

User avatar
Arnie De Beer
Laning Co-ordinator
Posts: 3399
Joined: Mon Nov 10, 2008 10:34 pm
Vehicle: Defender 90 & Defender 110
Real Name: Rick
Location: Andover

Re: spare wheel carrier mod for 33" wheels

Post by Arnie De Beer » Sat Oct 10, 2015 1:44 pm

You can buy modded carriers for bigger tyres but why buy when you can adapt what you have for free :gr8:
I'VE BEEN GIVING IT A LOT OF THOUGHT AND I DON'T THINK THAT BEING A RESPONSIBLE ADULT IS GONNA WORK FOR ME :|

User avatar
Davey Boy
Advanced Driving Instructor
Posts: 1617
Joined: Thu Apr 23, 2009 7:37 am
Vehicle: Nissan Patrol ZD30dti SVE
Real Name: Davey
Location: Dartmoor

Re: spare wheel carrier mod for 33" wheels

Post by Davey Boy » Sat Oct 10, 2015 9:43 pm

.... and a very tidy job Gav! :gr8:
I was looking to cruise......now I Patrol!

User avatar
Steve5car
Laning Co-ordinator
Posts: 3326
Joined: Sun Nov 07, 2010 8:55 pm
Vehicle: land rover discovery 1 , 3" lift,winch bumper,mud tyres,snorkel,steering guard ,etc
Real Name: Steve
Location: Andover Hampshire
Contact:

Re: spare wheel carrier mod for 33" wheels

Post by Steve5car » Sun Oct 11, 2015 9:48 pm

Perfect , I wonder if this works for a disco 1?

User avatar
mudmagnet
Laning Co-ordinator
Posts: 3169
Joined: Sun Jun 29, 2008 4:51 pm
Vehicle: td5 disco
Real Name: gavin
Location: Farnborough Hampshire

Re: spare wheel carrier mod for 33" wheels

Post by mudmagnet » Mon Oct 12, 2015 6:37 pm

Not sure if it is the same for a d1 but I found you could get a 265/75/16 tyre on the carrier without any mod when I had a d1
i'm so skint i cant even pay attention

User avatar
Dirty_Smurf
Laning Co-ordinator
Posts: 2037
Joined: Fri Jul 29, 2011 10:17 am
Vehicle: 300 tdi disco rooflights steering guard 2 inch lift td5 facelift lights also a LR D3 with AT's
Real Name: tony pearce
Location: Aborfield Reading
Contact:

Re: spare wheel carrier mod for 33" wheels

Post by Dirty_Smurf » Mon Oct 12, 2015 7:31 pm

:yipi: good little mod that's gav :gr8:
Just call me Tony
Swift & Bold

DiscoTD5
Full Licence
Posts: 36
Joined: Mon Jun 16, 2014 1:29 pm
Vehicle: Discovery 2 4.6L V8.
4" lift with 33" Cooper ST Max tyres.
Real Name: Jordan

Re: spare wheel carrier mod for 33" wheels

Post by DiscoTD5 » Sun Jan 17, 2016 7:07 am

mudmagnet wrote:my 265/75/16 measure about 32" so you should just about get a 33" tyre on the carrier with this mod


When I did this mod for my 33" tyres it didn't quite give enough height.


I had to raise it up another ~20mm. No pics but I basically went back to the original center whole and re-drilled the top and bottom instead.
